| KOD | A | B | C | D | D1 | L | M | O-RING |
|
DRA 330-38 |
R 3/8″ | 27 | 18 | 30 | 12 | 6.5 |
M 6X20 |
15.88X2.62 |
|
DRA 330-12 |
R 1/2″ | 27 | 18 | 30 | 12 | 6.5 |
M 6X20 |
15.88X2.62 |
|
DRA 335-38 |
R 3/8″ | 30 | 19 | 35 | 14 | 6.5 |
M 6X20 |
18.72X2.62 |
|
DRA 335-12 |
R 1/2″ | 30 | 19 | 35 | 14 | 6.5 |
M 6X20 |
18.72X2.62 |
|
DRA 335-34 |
R 3/4″ | 30 | 19 | 35 | 14 | 6.5 |
M 6X20 |
18.72X2.62 |
|
DRA 340-12 |
R 1/2″ | 38 | 22 | 40 | 19 | 8.5 |
M 8X25 |
22X3 |
|
DRA 340-34 |
R 3/4″ | 38 | 22 | 40 | 19 | 8.5 | M 8X25 |
22X3 |
|
DRA 348-34 |
R 3/4″ | 44 | 27 | 48 | 19 | 8.5 | M 8X25 |
29X4 |
|
DRA 348-1 |
R 1″ | 44 | 27 | 48 | 19 | 8.5 | M 8X25 | 29X4 |
|
DRA 351-34 |
R 3/4″ | 45 | 27 | 51 | 24.5 | 10.5 |
M 10X25 |
29X4 |
|
DRA 351-1 |
R 1″ | 45 | 27 | 51 | 24.5 | 10.5 |
M 10X25 |
29X4 |
|
DRA 356-34 |
R 3/4″ | 45 | 27 | 56 | 24.5 | 10.5 |
M 10X25 |
29X4 |
|
DRA 356-1 |
R 1″ | 45 | 27 | 56 | 24.5 | 10.5 |
M 10X25 |
29X4 |
