| KOD | A | B | C | D | D1 | L | M | O-RING |
|
DRA 430-38 |
R 3/8″ |
40 | 18 | 30 | 12 | 6.5 |
M 6X20-6X35 |
15.88X2.62 |
|
DRA 430-12 |
R 1/2″ |
40 | 18 | 30 | 12 | 6.5 |
M 6X20-6X35 |
15.88X2.62 |
|
DRA 435-38 |
R 3/8″ |
42.5 | 18 | 35 | 14 | 6.5 |
M 6X20-6X35 |
15.72X2.62 |
|
DRA 435-12 |
R 1/2″ |
42.5 | 18 | 35 | 14 | 6.5 |
M 6X20-6X35 |
15.72X2.62 |
|
DRA 440-12 |
R 1/2″ |
47.5 | 24 | 40 | 17 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRA 440-34 |
R 3/4″ |
47.5 | 24 | 40 | 17 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRA 455-34 |
R 3/4″ |
54 | 29 | 55 | 25 | 8.5 |
M 8X45-8X60 |
29X4 |
|
DRA 455-1 |
R 1″ |
54 | 29 | 55 | 25 | 8.5 |
M 8X45-8X60 |
29X4 |
