| KOD | P | A | B | C | D | D1 | L | M | O-RING |
|
DRAE 435 M22 |
L15 |
M22X1.5 |
45 | 25 | 35 | 14 | 6.5 |
M 6X20-6X35 |
18.72X2.62 |
|
DRAE 435 M24 |
S16 |
M26X1.5 |
45 | 25 | 35 | 15 | 6.5 |
M 6X20-6X35 |
18.72X2.62 |
|
DRAE 435 M26 |
L18 |
M24X1.5 |
45 | 25 | 35 | 15 | 6.5 |
M 6X20-6X35 |
18.72X2.62 |
|
DRAE 435 M30 |
S20 |
M30X2 |
40 | 25 | 35 | 15 | 6.5 |
M 6X20-6X35 |
18.72X2.62 |
|
DRAE 440 M22 |
L15 |
M22X1.5 |
40 | 28 | 40 | 20 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRAE 440 M26 |
L18 |
M26X1.5 |
40 | 28 | 40 | 20 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRAE 440 M30 |
L22 |
M30X2 |
40 | 28 | 40 | 20 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRAE 440 M30 |
S20 |
M30X2 |
40 | 28 | 40 | 20 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRAE 440 M36 |
L28 |
M36X2 |
40 | 28 | 40 | 20 | 6.5 |
M 6X20-6X35 |
22X3 |
|
DRAE 455 M30 |
S20 |
M30X2 |
46 | 24 | 55 | 16 | 8.5 |
M 8X20-8X50 |
29×4 |
