| TYPE | A | MAX FLO l/min-USgpm |
MAX PRESSURE bar-PSI | mm – inch | Ch. 1 | Ch. 2 | APPROX WEIGHT kg-lbt |
|||||
| B | L | |||||||||||
| VBRF180 | BSPP 1/8 | 5 (1,3) | 350 (5075) | 25 (0.98) | 48 (1.89) | 14 | 22 | 0,12 (0.26) | ||||
| VBRF140 | BSPP 1/4 | 15 (4) | 34 (1.34) | 62 (2.44) | 19 | 30 | 0,28 (0.6) | |||||
| VBRF380 | BSPP 3/8 | 30 (7.9) | 39 (1.54) | 73 (2.87) | 24 | 36 | 0,45 (1) | |||||
| VBRF120 | BSPP 1/2 | 45 (11.9) | 44 (1.73) | 83 (3.27) | 30 | 42 | 0,63 (1.4) | |||||
| VBRF340 | BSPP 3/4 | 85 (22.4) | 300 (4350) | 54 (2.13) | 102 (4.02) | 36 | 50 | 1,06 (2.33) | ||||
| VBRF100 | BSPP 1 | 150 (39.6) | 250 (3625) | 65 (2.56) | 124,5 (4.90) | 42 | 60 | 1,8 (4) | ||||
| VBRF114 | BSPP 1-1/4 | 200 (52.8) | 75 (2.95) | 144 (5.67) | 50 | 70 | 2,78 (5.96) | |||||
